ST/PC-ST/PC Fiber Optic Patch Cable Om3 Duplex Aqua color Quality om3 om4 Fiber Distribution Frame networking
om3 Fiber Optic Patch Cable
,Duplex Fiber Optic Patch Cable
OM3 patch cable connection, this cost-effective solution offers high-speed 10 gigabit performance through the use of Laser-Optimized Multimode Fiber (LOMMF). Specifically designed for Ethernet applications, this high-quality multimode fiber optic patch cable offers exceptional durability and is resistant to pulls, strains, and impacts that may occur during installation. Every cable is 100% optically inspected and rigorously tested for insertion loss before it is delivered to you. Adopting a pull-proof jacket design, the 10G 50/125 OM3 multimode fiber is immune to electrical interference, ensuring smooth and uninterrupted data transmission.
Features
. 100% tested on optical performance (Insertion Loss Customer specified length & Return Loss)
. Standard colour is Yellow, Orange, Aqua or Purple, other colors available upon request
. Cable outer jacket available in PVC, Low Smoke Zero Halogen (LSZH)
. PC, UPC, APC connectors type available
. High concentricity 2.5mm ceramic ferrule for FC, ST, SC and 1.25mm ceramic ferrule for LC and MU
. Available in G652D, G657A, OM1, OM2, OM3 and OM4
. Position A/Position B markings
. Available in 0.9mm, 1.6mm, 2.0mm, 3.0mm sizes
Technical parameters
| Characteristic | Item | Test condition | Single mode fiber | Multimode Fiber | |
| Optical property | Insertion Loss (dB) | UPC | LED | <0.2dB | <0.4dB |
| APC | <0.3dB | <0.4dB | |||
| Return Loss (dB) | UPC | LD | >55dB | >25dB | |
| APC | >65dB | – | |||
| Mechanical test | Impulse test | 1.8 height, 8 times | <0.1dB | <0.1dB | |
| Vibration test | 10-60Hz, 1mm full amplitude | <0.1dB | <0.1dB | ||
| Plug service life | Above 1000times | <0.1dB | <0.1dB | ||
| Tensile strength | >50N | <0.1dB | <0.1dB | ||
| Environmental property | High temperature test | +85ºC, 96hs | <0.2dB | <0.2dB | |
| Cryogenic test | -40oC,96hs | <0.2dB | <0.2dB | ||
| Damp heat test | +40°C,90-95%RH,96hs | <0.2dB | <0.2dB | ||
Company Profile:
Shandong Yibo Optronics Technology Co., Ltd. (Ebocom®), established in 2012, is located in the beautiful spring city
of Jinan, covering an area of 26,600 ㎡ . It is a high-tech enterprise focusing on the research and development, production, sales and service of optical cables and communication equipment. Ebocom® is committed to the research, development and application of optical cable products and communication
products. Our products include various types of optical cables (outdoor/indoor optical cables, ADSS, OPGW, mining
cables, FTTH drop cables, patch cord and pigtails) as well as optical cable-related connectors, accessories and
equipment. Widely used in telecom operators, data centers, enterprise networks and other communication
infrastructure fields. The products strictly implement national standards and have obtained ISO9001, ISO14001, ISO45001, ISO50001, TLC certification, and National Radio and Television Administration network access certification. It also has 3 invention patents and 27 utility model patents. Ebocom® focus on R&D innovation and constantly pursue advancement in technology to meet the changing needs
of our customers. The company actively introduces advanced foreign production equipment and inspection equipment (optical fiber coloring equipment, secondary coating equipment, OPGW unit tube production equipment, precision optical fiber detectors), and absorbs advanced domestic and foreign process technology to ensure the high quality and quality of products. reliability. In order to further ensure product quality, the company has established a strict management system and checks every step of the production process at all levels. Over more than ten years of continuous innovation and development, Ebocom® has won many honors, such as "High-tech Enterprise", "Gazelle Enterprise", "Specialized Special New specialized and sophisticated Enterprise", Shandong Province Excellent Management Innovation Enterprise", "AAA Credit Unit" , "Contract-abiding and Credit-worthy Unit", etc.
