1m SC-SC Duplex Fiber Patch Cord for High Speed Internet Low Loose Communication
SC-SC Duplex Fiber Patch Cord
,1m Duplex Fiber Patch Cord
The OM3 50/125μm multimode fiber has less attenuation when bent or twisted than conventional fiber. This makes installation and maintenance more efficient. It saves you more space for high-density cabling in data centers, enterprise networks, telecom rooms, server farms, cloud storage networks, and any other site that requires fiber connector cables.
This 50/125 OM3 fiber optic cable is the preferred solution based on 10/40/100G Ethernet connectivity and is compatible with passive network components such as 10G SR, 10G LRM, SFP+ transceivers.
Features:
- Duplex multimode fiber optic patch cable
- SC to SC connectors
- 50/125 OM3 fiber
- low-smoke, zero halogen (LSZH) rated jacket
Applications:
- Fiber Network Deployments
- Fast Ethernet
- Fibre Channel
- Infiniband
- ATM
- Gigabit Ethernet
- Other Data Applications Requiring High Transfer Rates
Insertion Loss:
| Fiber Type | Connector Type | Polishing Type | IL | RL |
| Single mode | FC, SC, LC, ST, E2000, DIN, D4, MU | PC | <0.2dB | >50dB |
| FC, SC, LC, ST, E2000, DIN, D4, MU | UPC | <0.2dB | >55dB | |
| FC, SC, LC, ST, E2000, DIN, D4, MU | APC | <0.2dB | >60dB | |
| MTRJ, MPO, ESCON, FDDI | / | <0.5dB | >35dB | |
| Multi mode | FC, SC, LC, ST, E2000, DIN, D4, MU | PC | <0.3dB | >30dB |
| MTRJ, MPO, ESCON, FDDI | / | <0.5dB | >30dB |
Company Profile:
Shandong Yibo Optronics Technology Co., Ltd. (Ebocom®), established in 2012, is located in the beautiful spring city
of Jinan, covering an area of 26,600 ㎡ . It is a high-tech enterprise focusing on the research and development, production, sales and service of optical cables and communication equipment. Ebocom® is committed to the research, development and application of optical cable products and communication
products. Our products include various types of optical cables (outdoor/indoor optical cables, ADSS, OPGW, mining
cables, FTTH drop cables, patch cord and pigtails) as well as optical cable-related connectors, accessories and
equipment. Widely used in telecom operators, data centers, enterprise networks and other communication
infrastructure fields. The products strictly implement national standards and have obtained ISO9001, ISO14001, ISO45001, ISO50001, TLC certification, and National Radio and Television Administration network access certification. It also has 3 invention patents and 27 utility model patents. Ebocom® focus on R&D innovation and constantly pursue advancement in technology to meet the changing needs
of our customers. The company actively introduces advanced foreign production equipment and inspection equipment (optical fiber coloring equipment, secondary coating equipment, OPGW unit tube production equipment, precision optical fiber detectors), and absorbs advanced domestic and foreign process technology to ensure the high quality and quality of products. reliability. In order to further ensure product quality, the company has established a strict management system and checks every step of the production process at all levels. Over more than ten years of continuous innovation and development, Ebocom® has won many honors, such as "High-tech Enterprise", "Gazelle Enterprise", "Specialized Special New specialized and sophisticated Enterprise", Shandong Province Excellent Management Innovation Enterprise", "AAA Credit Unit" , "Contract-abiding and Credit-worthy Unit", etc.
