CAT-6a FTP UTP CAT6 Lan Cable CAT 6 24AWG Copper Wire Stranded for Switch Port

Place of Origin Shandong,China
Brand Name EBOCOM
Certification ISO TLC
Model Number CAT6
Minimum Order Quantity 3050m
Price EXW ≥3050m $0.25/M ≥6010m $0.23/M
Packaging Details 305m/box,4boxes/carton,
Delivery Time 5-8 day
Payment Terms T/T
Supply Ability 5000KMS/day

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Minimum Order Quantity 3050m Packaging Details 305m/box
Delivery Time 7-15 Work Days Payment Terms L/C, T/T, Western Union
Place Of Origin Shandong ,China Brand Name Ebocom /OEM
Certification ISO9001,ISO45001,ISO14001 Model Number Cat6a Cable
Copper Conductor 0.48/0.5/0.52 Diameter 0.4-0.6mm
Highlight

24AWG CAT6 Lan Cable

,

UTP CAT6 Lan Cable

,

CAT6 Lan Cable

Leave a Message
Product Description

Product introduction:

The standard for Category 6A (augmented Category 6) is ANSI/TIA-568.2-D (replaces 568-C.2),defined by TIA for enhanced performance standards for twisted pair cable systems. It was defined in 2009. Cat 6A performance is defined for frequencies up to 500 MHz—twice that of Cat 6. Cat 6A also has an improved alien crosstalk specification as compared to Cat 6, which picks up high levels of alien noise at high frequencies.



The global cabling standard ISO/IEC 11801 has been extended by the addition of amendment 2. This amendment defines new specifications for Cat 6A components and Class EA permanent links. These new global Cat 6A/Class EA specifications require a new generation of connecting hardware offering far superior performance compared to the existing products that are based on the American TIA standard.The most important point is a performance difference between ISO/IEC and EIA/TIA component specifications for the NEXT transmission parameter. At a frequency of 500 MHz, an ISO/IEC Cat 6A connector performs 3 dB better than a Cat 6A connector that conforms with the EIA/TIA specification (3 dB equals 50% reduction of near-end crosstalk noise signal power; see half-power point)



Specifications
Cable Diameter 6.2 mm Color blue
Connector Type Booted, Snagless Conductor type 0.48/0.5/0.52mm
Type Ethernet Cable Cable diameter 0.4-0.6mm
Category Performance Rating Cat 6a Brand  OEM/EBOCOM
Indoor/Outdoor Indoor Application networking
Jacket Material PVC (Polyvinyl Chloride) Insulation HDPE
Jacket Rating Standard / Non-Rated Packing carton box
Shield Type UTP Wire Gauge 24 AWG
Shielded/Unshielded Unshielded Modle HSYV-6 4X2X0.5



Physical &electric properties

Max.Conductor DC Resistance20*C (ohms/km): 67
Insulation Resistance5000MQ*Km
Dielectric Strength:DC 2500V 2S
Operating Temperation:-40℃-+80℃
