GYXTW 8 Core G652D Outdoor Fiber Optic Cable With Central Loose Tube
GYXTW 8 core outdoor fiber optic cable
,G652D loose tube fiber cable
,outdoor fiber optic cable with central loose tube
Product Description
The GYXTW 8 core cable is built with a gel-filled central loose tube to protect fibers from moisture and environmental stress. The double-sided steel tape armor enhances tensile strength and rodent resistance, while the two parallel steel wires act as additional strength members, providing stability during aerial installation.
This model is widely used in outdoor FTTx deployments due to its durability, compact size, and smooth installation performance. It is compatible with both overhead (aerial) installations and duct/pipe laying.
Key benefits include:
-
Central Loose Tube Design – stable structure with excellent protection
-
Two Steel Strength Members – improved anti-tension performance
-
Steel Tape Armored Structure – crush-resistant, anti-rodent
-
G652D / G657 Single-Mode Fiber Options
-
Ideal for Aerial, Duct, and Outdoor Telecom Networks
-
UV-resistant and water-blocking construction
Technical Specifications
| Item | Details |
|---|---|
| Cable Type | GYXTW Outdoor Armored Fiber Optic Cable |
| Fiber Count | 8 Cores (Single-mode G652D / G657A1 / G657A2) |
| Structure | Central Loose Tube |
| Loose Tube Material | PBT |
| Filling Compound | Waterproof fiber gel |
| Strength Members | Two parallel steel wires |
| Armoring Layer | Corrugated steel tape armor |
| Outer Jacket | PE (UV-resistant) |
| Outer Diameter | Customized on request |
| Tensile Strength | High mechanical performance for aerial installation |
| Crush Resistance | High resistance due to steel tape armor |
| Temperature Range | –40°C to +70°C |
| Installation Method | Aerial, duct, outdoor pipelines |
| Applications | FTTH, backbone transmission, outdoor telecom networks, rural broadband, long-distance communication lines |
Applications
-
Aerial fiber optic network expansion
-
FTTH last-mile distribution
-
Backbone and metropolitan network construction
-
Outdoor telecom and ISP infrastructure
-
Rural broadband and FTTx deployment
-
Industrial park and campus network cabling
