quality Indoor Optic Cable 12 24core Multimode OM1 OM2 OM3 OM4 Distribution Use factory

Indoor Optic Cable 12 24core Multimode OM1 OM2 OM3 OM4 Distribution Use

Name: Indoor Optic Cable 12 24core Multimode OM1 OM2 OM3 OM4 Distribution Use
Brand: Shandong Yibo Optronics Technology Co., Ltd.
SKU: GJFJV-12B1
Price: 0.14 USD
Availability: InStock

Place of Origin:Shandong，China

Brand Name:EBOCOM

Certification:ISO TLC

Model Number:GJFJV-12B1

Minimum Order Quantity:2000M

Price:EXW ≥2000m $0.16/M ≥5000m $0.14/M

Standard Packaging:1. Iron-wooden drum or non-fumigation wooden drum,normal wooden drum. 2. Drum size can be designed,details will calculation for suitable for containers.

Delivery Time:5-8 day

Payment Terms:T/T

Supply Ability:5000KMS/day

Tags:

Indoor Fiber Cable

Indoor Optical Fiber Cable

Indoor Drop Cable

Product Details

Highlight:

Multimode Indoor Optic Cable

OM1 Indoor Optic Cable

Distribution Indoor Optic Cable

Product Name: GJFJV/GJFJH

Jacket: PVC /LSZH

Strength Member: Aramid Yarn

Fiber: Single Mode/multi Mode

Brand: Ebocom Or OEM

Product Description

Detailed Specifications & Features

Description

Indoor optical cables are a high-speed data transmission medium used to connect devices within buildings or data centers. They consist of optical fibers encased in protective sheaths and are designed for data transmission over relatively short distances. When optical cables are used indoors, safety and practicality are the main considerations. Therefore, optical cables for indoor use should be free of metals, halogens, be highly flexible, lightweight, and feature a completely dry design.

In recent years, indoor optical cables have become an important component of modern communication networks, as they can provide fast and reliable connections for enterprises, families and other organizations. Whether you are building a new data center, upgrading telecommunications infrastructure, or simply hoping to improve the speed and reliability of your internet connection, indoor optical cables can offer powerful solutions to meet your needs.

Applications

Mainly used for indoor wiring and connections between various indoor communication equipment, between equipment and instruments, and between instruments.

Mechanical Specifications

Cable Model	Outer Diameter (mm)	Weight (kg/km)	Tensile Strength(N)		Crush Resistance(N/100mm)		Bending Radius		Jacket Thickness(mm)
Cable Model	Outer Diameter (mm)	Weight (kg/km)	Long term	Short term	Long term	Short term	Dynamic	Static	Jacket Thickness(mm)
GJFJV-2F	3.6±0.2	12.5	180	440	300	1000	20D	10D	0.45±0.05
GJFJV-4F	4.7±0.2	17.6	180	440	300	1000	20D	10D	0.8±0.1
GJFJV-6F	5.2±0.2	22.8	180	440	300	1000	20D	10D	0.9±0.1
GJFJV-8F	5.8±0.2	26.7	180	440	300	1000	20D	10D	0.9±0.1
GJFJV-12F	6.3±0.2	32.7	180	440	300	1000	20D	10D	0.9±0.1
GJFJV-24F	8.0±0.2	53	200	660	300	1000	20D	10D	1.0±0.1
